6 Technical data
6 Technical data
6.1 General data
FCC ID: 2ASK2-SUTO-004
Parameters Flow selectable: Volumetric flow, working
condition flow, dry air flow,
Free Air Delivery (FAD),
mass flow
Consumption
Velocity (working condition)
Medium temperature
Medium pressure
Selectable units Volumetric Flow: m
3
/h, m
3
/min, l/min, l/s,
cfm
Mass flow: kg/h, kg/min, kg/s, t/h, lb/h
Consumption: m
3
, ft
3
, t, lb, l, kg
Velocity: m/s, ft/min
Temperature: °C, °F
Pressure: bar, psi, kPa, MPa
Reference conditions Selectable by users. Default ex-factory
settings:
compressed air: ISO1217 20°C, 1000 hPa
other gas: DIN1343 0°C, 1013.25 hPa
Principle of measurement Differential pressure with Pitot tube
Sensor Differential pressure sensor
Measuring medium Air, gas (non corrosive gas)
Operating temperature -40 … +230°C probe tube
-30 … +70°C housing
0 … +50°C display (Optional)
-10 ... +40°C PoE (Optional)
Turndown ratio 1:10 (min/max flow ratio)
Operating pressure 0 ... 1.6 MPa
Housing material PC + ABS
