6 Technical data
Material of the probe tube,
sensor head and the
screwing
Stainless steel 1.4404
Protection class IP65
Dimensions See dimensional drawing on page 15.
Display (optional) 2.4” colour graphics display with keypad
(optional)
Tube diameter 1.25” to 10” (greater diameters on request)
Screwing thread G 3/4” (ISO 228/1)
Weight 1.12 kg
6.2 Electrical data
Power supply 24 VDC, 150 mA
48 VDC, 100 mA (PoE)
6.3 Output signals
Analogue output Signal: 4 ... 20 mA
Scaling: 0 to maximum volume flow /
velocity
Accuracy: 0.06 mA
Pulse output 1 pulse per consumption unit
Isolated switch: max. 30 VDC / 200 mA
Pulse length: 30 … 120 ms depending on
the flow rate
Modbus output
(default setting)
See section 10.3 on page 41.
M-Bus output
(default setting)
See section 10.4 on page 43.
12 S430
