8 Installation
The 8-position pin/pair assignment on the RJ45 side must comply with
T568B wiring method. The sensor does not support T568A wiring
method.
M12 X-coded RJ45 Signal Color code
Pair
designation
1 1 Tx+ / +Vb / -Vb White-Orange (W-O)
Pair 2
2 2 Tx- / +Vb / -Vb Orange (O)
3 3 Rx+ / -Vb / +Vb White-Green (W-G)
Pair 3
4 6 Rx- / -Vb / +Vb Green (G)
5 7 NA / -Vb White-Brown (W-BR)
Pair 4
6 8 NA / -Vb Brown (BR)
7 5 NA/ +Vb White-Blue (W-BL)
Pair 1
8 4
NA/ +Vb Blue (BL)
S430 31
