10 Sensor signal outputs
If the flow rate is higher than 50 m
3
/s, l/s of ft
3
/s, the S430 cannot
output the pulses with default settings (one pulse per a consumption
unit).
In this case, you can set the pulse to 1 pulse per 10 consumption units
or 1 pulse per 100 consumption units using by the S4C-FS service app
or a connected display.
Example, with the setting of 1 pulse per 10 m
3
, the sensor sends one
pulse each 10 m
3
.
Example:
Volume flow
[m
3
/h]
Pulse length
[ms]
Max. consumption
[m
3
]
≦ 10800
120 10800
> 10800 60 28800
> 28800 30 57600
