NICE3000 User Manual Function parameter description
117
Function code Name Default Min. Unit Setting Range
F4-05 Low bit of leveling plate 0 1 065535
It can show the pulse number of leveling plates practical length. It is noted when auto-tuning
in shaft. Users can adjust it according to practical status.
Function code Name Default Min. Unit Setting Range
F4-06 High bit of oor high 1 0 1 065535
F4-07 Low bit of oor high 1 0 1 065535
F4-64 High bit of oor high 30 0 1 065535
F4-65 Low bit of oor high 30 0 1 065535
The bit of floor height i means the pulse number of height between floor i leveling plate to
oor (i+1) leveling plate. Every height corresponds to one number of 32 bit numbers in binary
system. Among
those, high 16 bit parallels high bit of this oor height, and low 16 bit parallels
low bit of this oor height.
For example: the oor height from oor 4 to oor 5 is F4-12=6F4-13=54321.In in binary it
shows as follows:
00000000000001101101010000110001
Practical pulse number will be displayed as 447537 in decimal system.
6.6 F5 Group Terminal Function Parameters
Function code Name Default Min. Unit Setting Range
F5-00
Driver switch time
and time-switching
automatically
3s 1 1200s
When theres calling from other floors in driver state, it will turn to the normal state
automatically after F5-00 time; then return to driver state after the running.
When the parameter of F5-00 is smaller than 5, the mentioned function is cancelled, then its
the same with the normal dri
ver function.
Function code Name Default Min. Unit Setting Range
F5-01 Selection function of
terminal X1
33 1 0059
F5-02 Selection function of
terminal X2
35 1 0059
F5-23 Selection function of
terminal X23
00 1 0059
F5-24 Selection function of
terminal X24
00 1 0059
