NICE3000 User Manual Function parameter description
143
6.13 FC Group Protection Function Parameters
FC-00
Selection of short circuit protection
detection to the earth after power on
Default 1 Min. Unit 1
Setting Range 01
It can detect if theres short circuit error to the earth when power on through the setting of
this function code. If this function is valid, the lift will detect just at the moment of power on. If
the motor is short circuit protection to earth through the detection, the system stops o
utputting
immediately and outputs E23 short circuit fault to earth.
0Forbidden; 1Allow.
FC-01
Optional protection selection Default 1 Min. Unit 1
Setting Range
Bit0Overload protection selection
0Forbidden
1Allowable
Bit1Output phase-failure selection
0Phase-failure protected
1Phase-failure unprotected
Bit2: Over-adjusting function selection
0: Over-adjusting function valid
1: Over-adjusting function invalidation
Bit3: E053 add door-close limit judgment
0:no new method
1:old method + old method
Bi
t4: door-closing limit judge light curtain
0:no re-opening
1:re-open the door
Bit5: DSP communication judgment
0:wire broken check
1:no check
Bit6: new method for parallel door block
0: use mew method
1: resume to 745 program
Bit7:reveling over-speed check
0:check
1:no check
This function parameter can set the over load protection and output phase-failure protection,
and its mainly used for factory detection
. Users neednt set it.
FC-02
Overload protection coefcient Default 1.00 Min. Unit 0.01
Setting Range 0.5010.00
This function codes referred value is overloading current. When the system detects that the
output current arrives to the FC-02×motors rated current and last out the special time, the
system will output E11 motor overload.
FC-03
Overload pre-warning coefcient Default 80% Min. Unit 1%
Setting Range 50100%
This function code referred value is motors overload current. When the system detects that
the output current arrives to the FC-03×motor rated current and last out the special time, the
system will output pre-warning signal.
