NICE3000 User Manual Function parameter description
145
6.14 FD Group Communication Parameters
Function code Name Setting Range Default Min. Unit
FD-00 Baud rate setting
0：300bps
1：600bps
2：1200bps
3：2400bps
4：4800bps
5：9600bps
6：19200bps
7：38400bps
5 1
FD-01 Data format
0: No check-out
1: Even check-out
2: Odd check-out
0 1
FD-02 Local address
0～127，0：
Broadcasting address
1 1
FD-03 Responding delay 0～20ms 10ms 1ms
FD-04
Communication
delaying time
0.0～60.0s ，0.0s：
invalidation
0.0s 0.1s
This group function codes can set NICE3000 RS232 Serial communication parameter for up bit
motor monitoring software communication. FD-00 sets Serial communication baud rate, FD-01
sets Serial communication data frames format, and FD-02 sets the local address of controller.
These parameters’ setting must be the same with the Serial communication parameters of
controller so that they can communicate normally. FD-03 sets the delaying tim
e of controller
transmitting data by the Serial port. FD-04 sets the overtime of the Serial port communication,
and the time of frame data transmitted must be within the time of FD-04 setting. Otherwise
communication error may occur.
6.15 FE Group Lift Function Setting Parameters
FE-00
Collective selective mode Default 0 Min. Unit 1
Setting Range 0、1、2
0：Full selective, lift responds to up call and down call.
1：Down selective, lift only responds to hall down call and doesn’t respond to hall up call.
2：Up selective, lift only responds to hall up call and doesn’t respond to hall down call.
