Function parameter description NICE3000 User Manual
112
F2-10
Running direction Default 0 Min. Unit 1
Setting Range l01
0: The same direction
1: The running direction choose reversal, position pulse direction choose reversal
2: The same running direction, position pulse direction choose reversal
3: The running direction choose reversal, position pulse direction choose the same
In this function code, it can choose reversal of running direction (Motors runnin
g direction
when the connection of motor didnt change), and position signal (Means F4-03 used for
identify the pulse direction of lifts position). For example, After the installation of the lift, up
running inspection while lifts actual running direction is down running, so running direction
needs choose reversal; while up running inspection, the position pulse F4-03 reduced (position
lower), s
o position pulse direction needs choose reversal.
Please pay attention to the setting of parameters while recover the default.
6.4 F3 Group Running Control Parameters
F3-00
Starting speed Default 0.010m/s Min. Unit 0.001m/s
Setting Range 0.0000.030m/s
F3-01
Time keeping Default 0.150s Min. Unit 0.001s
Setting Range 0.0000.500s
Setting of starting speed can increase the ability to overcome the static friction. But if the setting
of starting speed is too big, it can generate impact feeling at starting time. The using of two
parameters can smooth of lift starting.
F3-02
Acceleration Default 0.600m/s
2
Min. Unit 0.001m/s
2
Setting Range 0.2002.000m/s
2
F3-03
Inexion speedup time 1 Default 2.500s Min. Unit 0.001s
Setting Range 0.3004.000s
F3-04
Inexion speedup time 2 Default 2.500s Min. Unit 0.001s
Setting Range 0.3004.000s
The three function codes decide the S curve parameters of lift speedup running:
F3-02 is acceleration of S curve of lift speedup running.
F3-03 is the time which
is cost from 0 to the parameter F3-02 of S curve speedup stage. The
bigger this parameter is, the slower curve inexion is.
F3-04 is the time which is taken from the change of acceleration from 0 to that of F3-02 in the S
curve speedup stage. The bigger this parameter is, the slower the atter the curve inexion is.
