NICE3000 User Manual Structure of the control system and the component introduction
63
signal.
Disposal method: the X1 and X3 that the leveling signal connect to the NICE 3000 control
system, break the door area signal and the X2, and connect the door area signal to the FL1
and FL2, that means connect both FL1 and FL2 to door area signal. If the door area signal is
N.C inputting, please use the relay to switch to N.O. inputting. When the elevator is up running,
detect out the up leve
ling signal and the FL1 and FL2 are all valid, the advanced door-open
function is operated. The down run is the same. Function codes setting
NICE3000 I/O Parameter setting
F5-02 X2 03
F5-08 X8 22
F5-30 Y3 03
In the application with NICE 3000 system, accordingly as the users manual, set the F5-02 as
03 door area N.O. inputting, F5-08 as 22 advanced door-open output feedback N.O. inputting,
and F5-30 as 3 advanced door-open contactor outputting
Remark:
On the actual application, users can choose any I/O function codes by parameter setting
On the sc
heme 2, short the FL1 and FL2 to test (need the professional monitor). Considering
from safety, the 2 re-leveling door area signals are recommended to ensure the smooth running
of the system.
3.6 Voice landing report (CHM)
Wiring 1)
4PIN terminals are 24VMOD+MOD-COM.
24 v pin connect to DC 24v power +, COM connect to DC 24v power -.
MOD+MOD- are the positive/negative of the 485 communication in
terface differential signal.
The voice reporter will be ready for work after the correct wiring as above introduction.
Parameter setting2)
The three buttons are FUN+ -.
Settable parameter table:
Serial No. Function Reference Default Specication
1
Language
select
Chinese, English,
Chinese/English
Chinese
2
Background
music select
110 1
3 Music volume 116 12
1mute 16Max.
volume
4
Voice report
volume
116 12
1:mute 16Max.
volume
