NICE3000 User Manual Function parameters tables
83
5.2 Function Parameters Tables
5.2.1 Groups of Function Parameters
Press UP/DOWN button after pressing PRG, all the first level menu displayed are the
groups of function. Details as follows:
F0——Basic parameters F9——Time parameters
F1——Motor parameters FA——Keyboard setting parameters
F2——Vector control parameters FB——Door function parameters
F3——Running control parameters FC——Protect function parameters
F4——Floor parameters FD——communication parameters
F5——Terminal function parameters FE——Lift function setting parameters
F6——Lift basic parameters FF——Factory parameters
F7——Testing function parameters FP——User parameters
F8——Reinforce function parameters
5.2.2 Parameters tables
Function
Code
Name Setting Range Min. Unit Default
Modi-
cation
F0 Basic Parameters
F0-00 Control modes
0: Speed sensorless vector control(SVC)
1: Vector control(VC) with speed sensor
1 1
F0-01
Command
source
selection
0Operating panel command channel
1Distance control
1 1
F0-02
Operating panel
speed
0.050F0-04 0.001m/s 0.050m/s
F0-03
Elevator Max.
running speed
0.250F0-04 0.001m/s 1.600m/s
F0-04
Elevator rated
speed
0
.2504.000m/s 0.001m/s 1.600m/s
F0-05 Lift rated load 3009999 kg 1 kg 1000 kg
F0-06 Max. frequency 20.00Hz99.00Hz 0.01Hz 50.00Hz
F0-07
Carrier
frequency
0.516.0kHz 0.1kHz 6kHz
F1 Motor Parameters
F1-00
Encoder type
selection
0: SIN/COS increment (ERN 1387)
1: UVW increment
1 1
F1-01 Rated power 1.175.0kW 0.1kW
Depending
on the
model
F1-02 Rated voltage 0440V 1V 380V
F1-03 Rated current 0.00655.00A 0.01A
Depending
on the
mo
del
F1-04
Rated
frequency
0.0099.00Hz 0.01Hz 50.00Hz
F1-05
Rated rotation
speed
03000rpm 1 rpm 1460 rpm
