The lift will return to the landing when the system is in fire landing state.
F6-04
Stop landing Default 1 Min. Unit 1
Setting Range The lowest landing(F6-01)～The highest landing(F6-00)
When lift is in stopping state, it will return to this landing after completing control box command.
Function code Name Default Min. Unit Setting Range
F6-05 service oor 1 65535 1 0～65535
F6-06 service oor 2 65535 1 0～65535
F6-05 set what kind of oors command lift respond in oors 1~16. F6-06 set what kind of oors
command lift respond in oors 17~31.
The setting way of F6-05 service oor 1:
The oor service is controlled by binary system number of 16 bit. The binary system number
express the floor 1~16 from l
ow bit to high bit, The setting relevant bit 1express that lift
responds to this oor’s calling, and the setting relevant bit 0 express that lift doesn’t respond
to this oor’s calling. For example, oors in need of service are listed as follows:
Binary
digit
Relevant
oor
Service
or not
Binary bit
setting
Binary
digit
Relevant
oor
Service
or not
Binary bit
setting
Bit0 Floor 1 ON 1 Bit8 Floor 9 OFF 0
Bit1 Floor 2 OFF 0 Bit9 Floor 10 ON 1
Bit2 Floor 3 ON 1 Bit10 Floor 11 ON 1
Bit3 Floor 4 ON 1 Bit11 Floor 12 OFF 0
Bit4 Floor 5 ON 1 Bit12 Floor 13 ON 1
Bit5 Floor 6 ON 1 Bit13 Floor 14 ON 1
Bit6 Floor 7 ON 1 Bit14 Floor 15 ON 1
Bit7 Floor 8 OFF 0 Bit15 Floor 16 ON 1
The relevant binary digit setting is added in the list. The binary bit is 1111011001111101,and the
relevant algorism number is 63101,so F6-05 should be set as 63101.
The setting way of F6-06 is the same with F6-05.
F6-07
Group control number Default 1 Min. Unit 1
Setting Range 1～8
It can be used to choose lift number of group control:
1： Single lift running
2：2 parallel lift running
3~8: Group control running (need the cooperation of group control panel MCTC-GCB-A)
