NICE3000 User Manual Function parameter description
137
Binary bit Parameter
Display or
not
Binary bit
setting
Binary bit Parameter
Display or
not
Binary bit
setting
Bit4
Output
current
Display 1 Bit12
Car top
input state
Not
display
0
Bit5
Output
frequency
Display 1 Bit13
Car top
output
state
Not
display
0
Bit6
Input
terminal
low bit
Not
display
0 Bit14
System
state
Display 1
Bit7
Input
terminal
high bit
Not
display
0 Bit15
Preset
torque
current
Not
display
0
The setting binary number is 0100100000110111, the corresponding algorism number is 18487,
and FA-01 should be set as18487.These displaying parameter can be switched by shift key in
control keyboard.
FA-02
Stop display Default 65535 Min. Unit 1
Setting Range 0～65535
This function code is made up of binary numbers with 16 emic that displays 12 kinds of
stopping state parameters. The displaying parameters can be switched by shift key on the
control keyboard in the following list. The setting way is the same with FA-01.
Bit0 Rated speed Bit6 Current station
Bit1 Bus voltage Bit7 Car load
Bit2 Input terminal low bit Bit8 Rated lift slowdown distance
Bit3 Input terminal high bit Bit9 Car top input state
Bit4 Output terminal Bit10 Car top output state
Bit5 Current oor Bit11 System state
The stopping and running parameters are useful and important reference for the technician
when adjusting the lift. The specific meaning of each variable is
described as follows:
Running speed: is the actual speed when the lift is running. It’s the feedback speed of rotation
encoder whose maximum value is the fasted speed (F0-03) of the lift, with the unit m/s.
Setting speed: is the speed of NICE3000 when it’s running. It’s gained by the theoretical
calculations with the unit m/s.
Bus voltage: is the value of DC bus voltage with the unit V.
Output voltag
e: is the valid value of equivalent voltage when NICE3000 outputs PWM wave
form, with the unit V.
Output current: is the valid value of the actual current when NICE3000 drive motor is running,
with the unit A.
Output frequency: is the actual frequency when the motor is running with the unit Hz. This
parameter is fixed corresponding with the running speed.
