Suzhou Monarch Control Technology MCTC-CTB-A User Manual

NICE3000 User Manual Fault diagnosis and countermeasures
179
Operate
panel
display
Digital
tube
display
Fault
description
Fault cause Disposal way Sort
Err 35 E35
Shaft auto-
tuning data
abnormity
1 .not on the bottom oor
when start
2 .no levelling signal input
after runing for 45s
3 .oor gap too small
4 .the maxium oor amount
not accord with the set
value
5 .oor pulse record
abnormal
6 .system not in the
inspection state when do
the auto-tuning
Err 35 occurred before
the
run contactor pick-up
1 .check whether the 1st
down forced deceleration
is valid
2 .F4-01=1
3 .whether the inspection
switch on the inspection
state and able to done the
inspection run
4 .F0-00=1
Err 35 occurred as soon as
the run contactor pick-up
1 .check whether the
inspection switch on the
inspection state
Err 35 occurred during
running
1 .check whether running
overtime, , run over the
time of Err 35 occurred
when meet the 1st levelling
position
1 .Whether the F4-03
INCREASE WHEN UP,
DECREASE WHEN
DOEN, switch the main
board PGA and PGB if it is
not .
2 .Level sensor N .O, N .C
.setting error .
3 .level sensor signal ash,
check the plate
Err 35 during running:
1 .check whether run
overtime of F9-02 setting
value, and no receiving of
levelling signal
2 .the oor distance less
than 50cm, check the
sensor
3 .the F6-00 setting too
small
Run to the top oor:
1 .the 1
st
forced slowdown
is valid and juadge on the
door-area, check whether
the learned oor amount
are same as the setting of
F6-00 and F6-01 .
2 .Error occurs if the lifting
height less than 50cm
Err35 occures when
power-on
Check whether the plate
length is 0 after power-on
4
