Function
Code
Name Setting Range Min. Unit Default
Modifi-
cation
F5-01
Select function
of terminal X1
00：No function
01：N.O. input of up leveling
02：N.O. input of down leveling
03：N.O. input of door zone
04：N.O. input of Safety circuit feedback
05：N.O. input of Lock circuit feedback
06：N.O. input of running output feedback
07：N.O. input of brake output feedback
signal
08：N.O. input of inspection signal
09：N
.O. input of inspection up
10：N.O. input of inspection down
11：N.O. input of fire signal
12：N.O. input of upper limit signal
13：N.O. input of lower limit signal
14：N.O. input of over loading
15：N.O. input of full load
16：N.O. input of NO.1 up force reducer
17：N.O. input of NO. 1 down force reducer
18：N.O. input of NO.2 up force reducer
19：N.O. input of NO. 2 down force reducer
20：N.O. input of NO.3 up
force reducer
21：N.O. input of NO. 3 down force reducer
22：advanced door-opening module output
feedback N/O input
23： N.O. input of firemen opening and
closing
24：N.O. input of door motor light-beam
curtain1
25：N.O. input of door motor light-beam
curtain2
26：N.O. input of brake output feedback 2
27：Valid N.O. input of UPS
28：N.O. input of lift-locking
29 : N.O. input 2 of safety signal
30 : N.O. input of
synchronous motor U,V,W
jump-out feedback
31 : N.O. input of door lock circuit2 feedback
33：N.C. input of up leveling
34：N.C. input of down leveling
35：N.C. input of door zone
36：N.C. input of Safety circuit feedback
37： N.C. input of Lock circuit feedback
38：N.C. input of running output feedback
39： N.C. input of brake contactor feedback
signal
40：N.C. input of inspection signal
41：N.C. input of inspectio
n up
42：N.C. input of inspection down
43：N.C. input of fire signal
44：N.C. input of upper limit signal
45：N.C. input of lower limit signal
46：N.C. input of over loading
47：N.C. input of full loading
48：N.C. input of NO.1 up forced deceleration
49：N.C. input of NO. 1 down forced
deceleration
50：N.C. input of NO.2 up forced deceleration
51：N.C. input of NO. 2 down forced
deceleration
52：N.C. input of
NO.3 up forced deceleration
53：N.C. input of NO. 3 down forced
deceleration
54：N.C. input of advanced door-opening
module feedback
55： N.C. input of firemen opening and closing
56：N.C. input of door motor light-beam
curtain1
57：N.C. input of door motor light-beam
curtain2
58：N.C. input of brake output feedback2
59：Valid N.C. input of UPS
60 : N.C. input of lift-locking signal
61 : N.C. input 2 of safety
signal
62 : N.C. input of synchronous motor U,V,W
jump-out feedback
63 : N.C. input of door lock circuit 2 feedback
1 33 ★
F5-02
Select function
of terminal X2
1 35 ★
F5-03
Select function
of terminal X3
1 34 ★
F5-04
Select function
of terminal X4
1 04 ★
F5-05
Select function
of terminal X5
1 05 ★
F5-06
Select function
of terminal X6
1 38 ★
F5-07
Select function
of terminal X7
1 39 ★
F5-08
Select function
of terminal X8
1 22 ★
F5-
09
Select function
of terminal X9
1 40 ★
F5-10
Select function
of terminal X10
1 09 ★
F5-11
Select function
of terminal X11
1 10 ★
F5-12
Select function
of terminal X12
1 44 ★
F5-13
Select function
of terminal X13
1 45 ★
F5-14
Select function
of terminal X14
1 48 ★
F5-15
Select function
of terminal X15
1 49 ★
F5-16
Select function
of terminal X16
1 50 ★
F5-17
Select function
of terminal X17
1 51 ★
F5-18
Select function
of terminal X18
1 00 ★
F5-19
Select function
of terminal X19
1 00 ★
F5-20
Select function
of terminal X20
1 00 ★
F5-21
Select function
of terminal X21
1 00 ★
F5-22
Select function
of terminal X22
1 00 ★
F5-23
Select function
of terminal X23
1 00 ★
F5-24
Select function
of terminal X24
1 00 ★
