Application parameters W3
Application parameters are parameter-specific for the selected application.
Display image Description
P_1001 4
System1=H,2=C,3=ChOv,4=HC
min 1 max 4
Indicates how the climate
system should operate for
heating and cooling.
1 = Heating only
2 = Cooling only
3 = Change-over function
4 = Heating/Cooling
P_1002 1
0=ext.temp, 1 or 2 room units
min 0 max 2
Indicates whether one or
two room units are used..
(0=The controllers temp. sensor
is used, 1=1 unit, 2=2 units If 2
units are used they should be
connected with a cable.
P_1003 10 C
Frost guard temp.
min 5 max 12
Indicates at which temperature
the frost protection should
switch in.
P_1008 90 %
Boost flow SA %
min 0 max 1
Indicates the supply airflow for
BOOST.
P_1010 0
Emergency func SA damper
min 0 max 1
Indicates which blade position
the damper in the supply air
duct should have in event of
fire.
0 = Closed
1 = Open
P_1011 10 %
Stand-by flow SA %
min 0 max 100
Indicates the supply airflow for
STOP.
P_1012 90 %
Boost flow EA %
min 0 max 100
Indicates the extract airfl ow for
BOOST.
P_1014 0
Emergency func exhaust damper
min 0 max 1
Indicates whether the damper
in the extract air duct should be
open or closed in the EMERG
mode.
(0=Closed, 1=Open)
P_1015 10 %
Stand-by flow EA %
min 0 max 100
Indicates the extract airflow
for STOP.
P_1016 50 %
Normal flow SA %
min 0 max 100
Indicates the supply airflow for
AUTO.
P_1017 50 %
Normal flow EA %
min 0 max 100
Indicates the extract airflow for
AUTO.
