Signed-off or out of service
A station that is out of service is not available to send or receive carriers. When the station is out of ser-
vice, the default state is modified as follows.
 Status screen shows all positions occupied
 If available, an empty turnstile position faces forward
 Security door is closed
Badge- or PIN-secure station locked
A badge- or PIN-secure station requires the presentation of credentials for access to a station. When a
station is locked, the default state is modified as follows.
 Log-in screen displayed
 Empty turnstile position faces forward
 Security door is closed
Badge- or PIN-secure station unlocked
A badge-or PIN-secure station is in the unlocked state when a user with valid credentials is currently
logged in to the station. In a badge- or PIN-secure state, the default state is modified as follows.
 Status screen displayed
 ID of the user who is currently logged in is shown in the lower-right corner of the screen, along
with a “Log out” option
 Empty turnstile position faces forward
 Security door is open
Delivery of carriers from the system to the Nexus Station
The system can deliver a carrier from anywhere in the PTS to a Nexus Station at any time.
Status: carrier incoming
For a carrier to be sent to a station, the events described next must occur. These events occur when a
send transaction is initiated and again at turn-around of the final cycle to ensure that the destination is
mechanically capable of receiving the carrier. When the carrier lands at the slide plate, the system recog-
nizes it as having “landed.” This the carrier arrival state is initiated by the system.
1 User elsewhere in the system initiates a transaction to send a carrier to a Nexus Station.
2 The air valve and slide plate at the Nexus Station are closed.
3 The brake is engaged.
4 The top sensor is cleared in the system.
5 A compartment is reserved in the turnstile.
6 The air path is aligned in the system, and the blower turns on pressure toward the station.
7 The Nexus Station awaits landing of the carrier.
