MECHANICAL PARTS | DRIP CONTAINER 26
APR/2017 TECHNICAL OPERATIONS AND MAINTENANCE GUIDE | NEXUS STATION
Nexus Station filter assemblies
Drip container
The drip container is a plastic bucket that sits below the turnstile to catch possible spills. It is removed and
cleaned as needed and can be replaced when necessary.
Nexus Station drip container
Door-bearing assembly
Four bearing assemblies hold in place the outer rods allowing movement of the security door. Replace the
full assembly when the bearing wears out.
Nexus Station door-bearing assembly
TABLE 9. Drip container
Part Number Description Recommended maintenance
91214501 Drip container and lid Clean or replace as needed
TABLE 10. Bearing assemblies
Part Number Description Recommended maintenance
56746801 Bearing assembly Replace when needed
Back filter
Base filter
Door filter
