NEXUS STATION | TECHNICAL OPERATIONS AND MAINTENANCE GUIDE APR/2017
59 ELECTRONICS | PRIMARY CONTROL BOARD
Nexus Station primary control board – upper left side
Nexus Station primary control board – right side
21 J40 — Not used —
22 J17 (Not labeled) HMI display power P17
23 J17 (Not labeled) Main power supply P16
TABLE 1. Nexus Station circuit board connections—primary control board
Ref. Board # Label Controls the . Component #
