11. CRANKCASE / CRANK
11-1
Mechanism Diagram ··························11-1
General information ···························11-2
Trouble diagnosis ······························11-2
Disassembly of crankcase ················ 11-3
Crankshaft Inspection ······················· 11-5
Assembly of crankcase····················· 11-6
Mechanism Diagram
Eng. Oil drain bolt
3.5~4.5kgf-m
0.8~1.2kgf-m
11
Home page
Contents
1.0~1.4kgf-m
0.8~1.2kgf-m
