14. FRONT BRAKE & FRONT WHEEL
14-4
Front Wheel
Removal
Raise the front wheels off the ground by placing a
jack or other support under the frame.
Remove the front wheel axle cover (4 screws).
Remove the front wheel nuts, and then remove
front wheels.
Installation
Install the front wheel and tighten the nuts.
Torque: 2.4kgf-m
Front Wheel Hub
Removal
Remove front brake caliper (2 bolts).
Remove cotter pin, wheel hub nut and washer.
Remove wheel hub and brake disk.
4 nuts
To this chapter contents
Wheel hub nut
Cotter pin
4 screws
2 bolts
