3. LUBRICATION SYSTEM
3-1
Mechanism Diagram······························3-1
Precautions in Operation······················ 3-2
Troubleshooting ···································· 3-2
Engine Oil··············································· 3-3
Engine Oil Strainer Clean······················3-3
Oil Pump ·················································3-4
Gear Oil···················································3-7
Mechanism Diagram
Valve Rocker Arm
Cam Shaft
Spray Lubrication
Spray Lubrication
Press-In Lubrication
Press-In Lubrication
Oil Route
Con-Rod
Oil Route
Oil Pump
Rotate Direction
Oil Strainer
