13. BODY COVER
13-8
Remove front fender front side bolts (2 bolts).
Remove the left crankcase cover duct.
Remove front fender upper bolt, and then remove
front fender and headlight.
Disassembly
Remove 3 screws to remove front emblem.
2 Bolts
To this chapter contents
1 Bolt
Duct
3 screws
