15. STEERING / FRONT SUSPENSION
15-4
Loosen 2 screws, and then remove handle left
switch and choke hosing.
Remove switch wire band.
Remove handle mounting bolt, and then remove
the handle upper holder, handle.
Remove 2 nuts to remove handle under holder
and meter bracket.
Installation
Install in reverse order of removal procedures.
Torque value:
Handlebar under holder nut 4.0kgf-m
Handlebar upper holder bolt 2.4kgf-m
2 screws
To this chapter contents
2 Nuts
4 socket bolts
