16. REAR BRAKE & REAR WHEEL & REAR CUSHION
16-6
Remove 4 nuts, and remove driven sprocket.
Bend out the rear axle nut fixed plate.
Bend out the rear wheel axle holder nut fixed
plate.
Remove rear wheel axle nuts.
Special tool:
Rear axle nut wrench (55mm)
Remove rear brake disk bracket and disk.
To this chapter contents
Fixed plate
4 nuts
Brake disk bracket
