8. V-BELT DRIVING SYSTEM
8-4
Left crankcase cover inspection
Remove 2 bolts to remove left crankcase cover
bearing setting plate.
Check bearing on left crankcase cover.
Rotate bearing’s inner ring with fingers.
Check if bearings can be turned in smooth and
silent, and also check if bearing outer ring is
mounted on cover tightly.
If bearing rotation is uneven, noising, or loose
bearing mounted, then replace it.
2 bolts
9 bolts
