1. Performance Tests – Verifying Specifications
Equipment Required
3
Table 1-1. Recommended Test Equipment (Continued)
Digital Multimeter
Input Resistance: 10 M
Accuracy: 0.04% at 1 Vdc
T HP/Agilent 34401A
40kV ac/dc High
Voltage Probe
Range: >= 5KV dc, input Z= 1 G,
Accuracy: 2%, 10 M load
T HP/Agilent 34300A
Clip-on Current Probe Range: >= 1 Amp dc
Output: 1 Vdc at 10 Amp dc
T HP/Agilent 34302A
Universal Counter Range: >= 500 MHz
Accuracy: 0.1 PPM
T HP/Agilent 53131A,
Opt 010, 030
CW Microwave
Counter
Range: >= 10 GHz
Accuracy: >= 0.1 ppm
T HP/Agilent 5350B,
Option 010
Spectrum Analyzer Frequency Range: >= 9.5 GHz
Resolution: 100 kHz / Division
Center Frequency Accuracy: 1 PPM
Input: Up to 1 watt input capability
Dynamic Range: 100 dB
T HP/Agilent 8566A/B
Input Probe 10:1 Divider (included with
54600A oscilloscope)
T HP/Agilent 10071A
Input Probe
1:1 1 M (for 50  measurements)
T HP/Agilent 10070A
RF Signal Generator Frequency Range: > 80 MHz
Power: >= +7 dBm
T HP/Agilent 8656B
Pulse Generator Repetition Rate: 10 Hz
Pulse Width: <= 10 usec
Output Voltage: >= +3V
T HP/Agilent 8111A
General-purpose DC
Power Supply,
Adjustable
0 - 10V,
>= 25 ma
T HP/Agilent E3610A
IBM-Compatible PC
MS-DOS 3.3 or later, 640 kB RAM,
1 serial (COM: ) Port
T Any Vendor
Service Accessories
Kit
Special Test Tools, Devices, and
Fixtures
T 05071-67003
Profiling Software For Online CBT Performance Testing
(See Title Page for download
instructions)
T 05071-13501
