Symmetricom 5071A Assembly And Service Manual

5. Replaceable Parts
How To Order A Part
176
Table 5-1. 5071A Replaceable Parts
Reference
Designation
Part Number Description
A1 Not Available Motherboard
A2 05071-60202 CBT Controller
A3 05071-60003 Microprocessor
A4 05071-60004 Digital Synthesizer
A5 05071-60272 87 MHz PLL Module
A6 05071-60006 Servo
A7 05071-60007 Interface
A8 05071-60008 1 PPS
A9 05071-60292 Frequency Multiplier Module
A10 05071-60210 Output Frequency Distribution Amplifier Module
A11 05071-60029 Power Steering Logic, Std
A11 05071-60033 Power Steering Logic, 48VDC Version
A12 05071-60212 DC-DC Power Converter Module
A12 05071-60279 DC-DC Power Converter , 48VDC Version
A13 05071-60213 Front Panel Module
A14 05071-60214 Signal Amplifier Module
A15 05071-60215 9.2 GHz Microwave Generator Module
A16 05071-60216 High Voltage Supply Module
A17 10890A Cesium Beam Tube, Long Life
A17 10891A Cesium Beam Tube, High Performance
A18 05071-60218 9.2 GHz PLL Module
A19 05071-60294 Reference Oscillator Module
BT1 1420-0514 Battery 12V 2.5 Ah Lead Acid
MP4 05071-00027 Cover, Top
MP9 05071-00028 Cover, Bottom
MP13 05071-00037 Cover, Side, Perforated
MP25 5041-8821 Standoff -Rear
MP27 5062-4071 Rack Kit – Front Handle
