2. Service
Pre-Troubleshooting Information
30
Table 2-1. Service Accessories Kit (05071-67003) Contents
Accessory Part Number Use
Service Manual 05071-90040 Corrective maintenance
Extender board for short PCAs 05071-60051 A4, 6, 7, 8 diagnosis
Extender board for long PCAs 05071-60052 A2,3 diagnosis
100 nA Current Source (powered by A6) 05071-60274 A14 diagnosis
SO-8 SMT Dip clip (#5250 ITT Pomona) 1400-1708 SMT signal access
SO-14 SMT Dip clip (#5251) 1400-1705 SMT signal access
SO-16 SMT Dip clip (#5252) 1400-1706 SMT signal access
SO-20 SMT Dip clip (#5253) 1400-1707 SMT signal access
