D450-08-00 1 I56-338-07
B401 PLUG-IN DETECTOR BASE
INSTALLATION AND MAINTENANCE INSTRUCTIONS
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
Before Installing
Please thoroughly read System Sensor manual I56-407,
Guide for Proper Use of System Smoke Detectors, which pro-
vides detailed information on detector spacing, placement,
zoning, wiring, and special applications. Copies of this
manual are available at no charge from System Sensor.
NOTICE: This manual should be left with the owner/user
of this equipment.
IMPORTANT: The detector used with this base must be
tested and maintained regularly following NFPA 72 require-
ments. The detector used with this base should be cleaned
at least once a year.
Specifications
Base Diameter: 10.2 cm (4.0 inches)
Base Height: 2.0 cm (0.8 inches)
Weight: 152 g (0.32 lb.)
Mounting: 50 mm box
60 mm box
Operating Temperature Range: –10° to +60°C (14° to 140°F) — European Installation
0° to 49°C (32° to 120°F) — US/Australian Installation
Operating Humidity Range: 10% to 93% Relative Humidity
Electrical Ratings — includes base and detector
Base And Smoke Detector Base And Heat Detector
System Voltage: 12/24 VDC 24 VDC
Maximum Ripple Voltage: 4 Volts peak to peak 4 Volts peak to peak
Start-up Capacitance: 0.02
µ
F Maximum 0.02
µ
F Maximum
Standby Ratings:* 8.5 VDC Minimum 15 VDC Minimum
35 VDC Maximum 35 VDC Maximum
120
µ
A Maximum 100
µ
A Maximum
Alarm Ratings: 4.2 VDC Minimum at 10 mA** 4.2 VDC Minimum at 10 mA**
6.6 VDC Maximum at 100 mA** 6.6 VDC Maximum at 100 mA**
Reset Voltage: 2.5 VDC Minimum 2.5 VDC Minimum
Reset Time: 0.3 Seconds Maximum 0.3 Seconds Maximum
Start-up Time: 34 Seconds Maximum 34 Seconds Maximum
* 1151E: 30 µA Maximum.
** Alarm current MUST be limited to 100 mA maximum by the control panel.
If used, the RA400Z Remote Annunciator operates within the specified
detector alarm currents.
General Description
This B401 plug-in detector base is used with System Sensor
smoke and heat detector heads. The capability of plugging
these detectors into a variety of special bases makes them
more versatile than equivalent direct-wired models. Refer
to the System Sensor catalog for other available plug-in de-
tector bases.
The B401 base is intended for use in 2-wire systems, with
screw terminals provided for power and remote annuncia-
tor connections.
For use with the following smoke detectors:
US Models: 1151, 1451, 2151, 2451, 2451TH, 5451
European Models: 1151E, 1451E, 2151E, 2451E, 5451E
Australian Models: 1151AUS, 1451AUS, 2151AUS, 2451AUS,4451AUS, 5451AUS
