Delivery units with base frame
Liftingbracketsareprovidedonthebaseframeofeachindividualunitforlifting.Forlifting,usesuitableliftingstraps
andusebracketswithsufcientliftinggripspacingorusespacersupportslongenoughtoensurethatthestrapsdonot
press against the casing of the delivered unit.
Caution
Theliftingbracketsareonlyremovedwhentheunitsareinplace,justbeforejoining.Intheeventof
relocation,thebracketsmustbereassembled.
Delivery of units without a base frame
Applyappropriateliftingstripesandliftingbeamswithsufcientdistancebetweenthehoistingpointsoradequate
spacer supports in order to prevent the stripes from pressing against the shipment unit casing.
Caution
Place the lifting straps under the pallet on the outside of the support and secure them against slipping off
the pallet.
High and short shipment units
Someshipmentunits,e.g.asectionwitharotaryheatexchanger,aheatexchanger,etc.,maybeofsignicantheight
with very small length. Extra attention should be devoted to preventing such shipment units from tipping over. In the
factory,suchshipmentunitsareprotectedsoastopreventtheriskoftheirtippingoverduringtransportandstorage
and endangering exposed persons.
Caution
High and short shipment units must be protected against tipping over. They may only be transported in
the vertical position!
1 Spacer
2 Spacing frame
3 Lifting strap
4 Unit casing
5 Lifting brackets
1 Lifting strap
2 Units casing
3 Pallet
