• Settheappropriaterateofthehoneycombhumidierbleed-off.Tothisend,carryoutachemicalanalysisofthe
supply water to obtain the necessary data, as follows:
CaCO3 content (mg/l), Ca+ content (mg/l), HCO3- content (mg/l), pH value. From the water quality diagram
(providedinthehoneycombhumidiermanufacturer’sinstructions),determinethebleed-offfactor,f0.Fora
particular unit, calculate the bleed-off water volume according to the following formula:
O = f
0
x E, where:
E is the amount of absorbed water (l/min)
O is the amount of bleed-off water (l/min)
• Setthebleed-offwaterowratebymeansofthebleed-offvalvebyturningthevalveknobtothecorresponding
number(totheleftortotheright),thencheckthebleed-offwaterowrate(capturethebleed-offwaterina
containerofaknowncapacity,notlessthan1litre,andmeasurethecontainerllingtime).Repeatthisprocedure
until the correct bleed-off rate is achieved.
Caution
Keep the inner and outer surface of the inspection glass clean. If you notice fouling, thoroughly clean the
glass immediately.
When honeycomb or droplet eliminator needs to be removed or replaced:
• xedpanelhastoberemoved,
• sealant on the external side has to be cut (1)
• two plate sheets have to be removed (2 and 3).
After maintenance they have to be readjusted to starting position.
3.9.3 High pressure humidier
Caution
Technical data, dimensional data, layout and maintenance are added to the ordered air unit as an
attachment.
