3.10 Electric control cabinet
Caution
See also section 3.1 General instructions.
The electric control cabinet consists of a connection part and a measuring part, which are mechanically separated from
eachother.Itconsistsofthefollowingbasicelements:cabinetsinks,doorwithpointclosingandlock,elementsforow
protection, separation and KS protection and measuring equipment.
An electric control cabinet may be installed inside the air handling unit casing, on the unit casing, on a separate pedestal
next to the unit or on the machine room wall. The site of the installation of the electric control cabinet is determined at
the time of placing the order, according to the customer’s request.
Electric control cabinet inside the air handling unit casing
Theelectriccontrolcabinetisinstalledinanemptysectioninsuchamannerthatitdoesnotobstructtheinowofairto
the adjacent functional elements or the maintenance thereof.
An electric control cabinet on the air handling unit casing
Anelectriccontrolcabinetisinstalledontheouterwallofaxedpanelinsuchamannerthatthecabinetitselfand
the electric cables do not obstruct access to the unit’s interior or access to the functional elements for operational and
maintenance purposes.
An electric control cabinet on a separate pedestal next to the air handling unit
The scope of supply from Systemair d.o.o. is the electric control cabinet itself, the wiring between the air handling unit
andtheelectriccontrolcabinet,andstart-up,ifsospeciedintheorderconrmation.
In such an arrangement, Systemair d.o.o. does not carry out the mounting of the electric control cabinet or any required
constructionworks(penetrations,cabletrays,layingofthepowersupplyandcontrolcablesfromtheairhandlingunitto
the electric control cabinet, etc.). These are the responsibility of the customer.
An electric control cabinet on the machine room wall
The scope of supply from Systemair d.o.o. may include the electric control cabinet itself, the wiring between the air
handlingunitandtheelectriccontrolcabinet,andthestart-up,ifsospeciedintheorderconrmation.
In such an arrangement, Systemair d.o.o. does not carry out the mounting of the electric control cabinet or any required
constructionworks(penetrations,cabletrays,layingofpowersupplyandcontrolcablesfromtheairhandlingunittothe
electric control cabinet, etc.). These are the responsibility of the customer.
4. REMOVAL AND DISPOSAL
Caution
See also section 3.1 General instructions.
At the end of unit’s service life, the device must be removed from use and decommissioned in accordance with
applicable environmental regulations and legislation. Disassembly of the unit may only be performed by an authorized
company.
All substances (eg oils, refrigerant, batteries) must be disposed of in accordance with local regulations.
All metal and plastic parts must be separated and sent for recycling.
