Dimensions and weight
A
D
E
C
B
11
1071
783 4040
266
133 133
133
Position Description
A Connection Supply air, Ø125mm
B Connection Exhaust air, Ø125mm
C Connection Outdoor air, Ø125mm
D Connection Extract air, Ø125mm
E Connection to cooker hood (if installed), Ø125mm
11 Mounting brackets (hanging installation)
12 Mounting brackets (wall installation)
Fig. 1
Weight: 45 kg
