VR 250 ECH/B Installation description
206609 (17-09-2010)
5 Systemair AB
GB
Component description VR 250 ECH/B
1
2
3
4
5
6
77
77
8
Position Description
1
Fan extract air
2
Fan supply air
3
Filter supply air
4
Filter extract air
5
Heat exchanger
6
By-pass duct
7
Mounting brackets
8
Electrical connection box
Fig. 2
