T Scale IP30 - Rear Display Installation

IP30 Label Printing Scale Operation Manual
- 9 -
3.4. Rear Display Installation
②
Connect male and female
connectors well
④
Insert pole with cable to the holder
⑤
Using the screw to fix the pole to
the holder
③ Take the cable connectors into
the pole
① Take out pole display assembly
