T Scale IP30 User Manual

IP30 Label Printing Scale Operation Manual
- 46 -
8. TECHNICAL DATA
8.1. General Specification
MODEL
IP30
Display
Operator Display: 10.1" TFT LCD Display
Customer Display: 7” Colored Display
Display Resolution
10”: 1280*800 px; 7”:800*480;
Max Capacity
6kg/15kg; 15kg/30kg
Min Capacity
40g; 100g
Readability
2g/5g; 5g/10g
Max. Divisions
2x3000e
Weighing Units
kg, g, tj, gj, lb, oz, lz
Pan size
380x272 mm
Accuracy Class
Class III
Housing
ABS Plastic and Stainless Steel pan
Touch Control Mode
Resistance Screen
CPU
A17 Quard Core
OS
LINUX
RAM
2G
Data memory
16G NAND flash
Interface
2*RS232; 1*RJ11; 4*USB2.0; 1*RJ45 ;WIFI
Optional
Receipt bracket
Operation Temperature
-10°C to 40°C
Operation Humidity
<85%
Stabilisation Time
1 Seconds typical
Power
100~240VAC main power cord ; Optional Adapter: Out put :DC 24V/6350mA
ADC
Sigma delta
Internal counts
600,000
ADC update
Max 60 times /second
Load Cell
BX6 C3 (T-Scale) or L6D C3 (Zemic)
Load cell drive voltage
Max 5V/150mA
Net weight
8.5 kg
Gross weight
9.5 kg
Dimension
L:508xW:400xH:589
