Chapter 3 - Parameter List
30
Code Description
Keypad
Display
Setting Range Units
Factory
Default
Adj.
During
Run
Page
3 (XCEL-L)
4 (XCEL-M)
5 (XCEL-H)
6 (Dc-brake)
7 (2nd Func)
9 (V1-Ext)
10 (Up)
11 (Down)
12 (3-Wire)
13 (Ext Trip-A)
14 (Ext Trip-B)
16 (Open-Loop)
18 (Analog Hold)
8, 15, 17, 20, 21,
22, 23, 24, 25, 26
(-Reserved-)
19 (XCEL Stop)
I/O-13
Multi-function Input Terminal ‘P2’
Define
I 13 Same as above I/O-12
- 1 (Speed-M) No
I/O-14
Multi-function Input Terminal ‘P3’
Define
I 14 Same as above I/O-12
- 2 (Speed-H) No
63
I/O-15 Terminal Input Status I 15
00000000 – 11111111
(bit set)
- 00000000 -
I/O-16 Terminal Output Status I 16 0 – 1 (bit set) - 0 -
66
I/O-17
Filtering Time Constant for Multi-
function Input Terminals
I 17 2 to 50 1 2 Yes 66
I/O-20 Jog Frequency Setting I 20 0.00 to (FU1-20) 10.00 [Hz] Yes 66
I/O-21 Step Frequency 4 I 21 0.00 to (FU1-20) 40.00 [Hz] Yes
I/O-22 Step Frequency 5 I 22 0.00 to (FU1-20) 50.00 [Hz] Yes
I/O-23 Step Frequency 6 I 23 0.00 to (FU1-20) 40.00 [Hz] Yes
I/O-24 Step Frequency 7 I 24 0 .00 to (FU1-20)
0.01
30.00 [Hz] Yes
66
I/O-25
Acceleration Time 1
for Step Frequency
I 25 0.0 to 999.9 [sec] 0.1 20.0 [sec] Yes
I/O-26
Deceleration Time 1
for Step Frequency
I 26 0.0 to 999.9 [sec] 0.1 20.0 [sec] Yes
I/O-27 Acceleration Time 2 I 27 0.0 to 999.9 [sec] 0.1 30.0 [sec] Yes
I/O-28 Deceleration Time 2 I 28 0.0 to 999.9 [sec] 0.1 30.0 [sec] Yes
I/O-29 Acceleration Time 3 I 29 0.0 to 999.9 [sec] 0.1 40.0 [sec] Yes
I/O-30 Deceleration Time 3 I 30 0.0 to 999.9 [sec] 0.1 40.0 [sec] Yes
I/O-31 Acceleration Time 4 I 31 0.0 to 999.9 [sec] 0.1 50.0 [sec] Yes
I/O-32 Deceleration Time 4 I 32 0.0 to 999.9 [sec] 0.1 50.0 [sec] Yes
I/O-33 Acceleration Time 5 I 33 0.0 to 999.9 [sec] 0.1 40.0 [sec] Yes
I/O-34 Deceleration Time 5 I 34 0.0 to 999.9 [sec] 0.1 40.0 [sec] Yes
67
