Number Por-
tion
Description
iqn.2015-
10.com.guid:
Base identification number/domain for all Tableau products (as
provided by the iSCSI naming authority).
sn-
000ecc5801000c.
The serial number of the specific TX1 in use, which serves as a unique
identifier within the domain.
sata.1
TX1 specific suffix. The default is the protocol of the drive being exported
with an incrementing number at the end. However, the user can edit
this portion of the IQN via the optional Suffix entry field on the iSCSI
Export setup screen (as shown below).
If successful, the final exported IQN is provided along with a listing of any initiator limits (IP
address and/or IQN values). The IQN of the exported drive should then be available for
selection via the Discovery function of an initiator on that same network.
104 Tableau TX1 User Guide Version 2.0
