TA-U1...U280
Instruction and Operating Manual
Misprints and technical changes reserved
25
3.3.15 Ethernetboard
X2 Connection to controlboard
X7 Connection ethernet
X8 Connection ethernet
S1
BR1
Ethernet 1401
X2
X7 X8
3.3.14 CanOpen
X2 Connection to controlboard
X7 Connection to CanOpen plug
S1 load resistor
On=top
OFF=bottom
X2
X7
S1
CanOpen 0701
ON
OFF
