Instruction and Operating Manual
TA-U1...U280
Misprints and technical changes reserved
46
6.0 Operation
6.1 Instructions of Safety
The operation should only be done by qualified personnel. Follow the advice in Chapter 1 and 2 about usability and
protection against irregular usage.
Caution - Danger !
Disconnect unit from mains before making any repairs. Only when the BUSS-
capacitors have discharged, (5 minutes after the device has been seperated
from line, the unit may be opened and worked on).
As with any form of electrical equipment, there is always a risk involved in the handling of
electrical machinery. The greatest care must always be exercised during installation and
maintenance. It is recommended that service is performed by authorized personnel only.
Make sure that the unit and the motor is properly grounded in order to avoid electrical hazzards!
Improper grounding will also cause damage to the electronic circuit and to the encoders of the
motor! The common connection of the electronic circuit can be jumpered, connected to ground
with 1MR or 100R.
6.2.1 Dip-switches
Before operating the drive it is necessary to check the configuration of the Dip-switches.
In general these Dip-switches are already properly configured with factory settings.
Nevertheless make sure that the configuration corresponds to your requirements.
Detailed information concerning the settings of these Dip-switches is provided in Chapter 5.2 - 5.4.
6.2.2 Setting of Motor Parameters
The motor parameters (Chapter 3.3) are programmed with standard parameters by the factory. The adjustment refers
to the nominal data of the selected motor and are documented in the applied test protocol.
