tae TA-U110 HT User Manual

TA-U1...U280
Instruction and Operating Manual
Misprints and technical changes reserved
9
3.2 Technical Data
3.2.1 Drive Specifications - Part numbers TA-U1…U280
The voltages, currents and power data in this tabel are nominal data at switch frequency 8 kHz. You will find the exact
value on the name plate.
If the 400V devices operate at voltage 480V, the output power will be increased at approx 20%.
Mains 3Ph 50/60 Hz Power Current (Output)
Voltage Current Output Loss I-Nominal I-Overload I-Peak
(disconnect)
BL-Motor AC-Motor control drive
(at 8kHz)
(at 8kHz)
TA-U1 19101-xxxx
230V 3,2 A 3,8 A 0,8 kW 30 W 4,5 A 7,0 A 12,5 A
TA-U2 19102-xxxx
230V 5,5 A 6,0 A 1,6 kW 45 W 7,5 A 10,7 A 19 A
TA-U4 HT 19105-xxxx
230V 13 A 14 A 4 kW 90 W 20 A 25,3 A 45 A
TA-U10 19110-xxxx
230V 19 A 21 A 6 kW 130 W 25 A 30 A 53 A
TA-U15 19115-xxxx
230V 24,5 A 26 A 8 kW 180 W 36 A 43 A 76 A
TA-U22 19122-xxxx
230V 36 A 39 A 12 kW 300 W 50 A 60 A 107 A
TA-U22 HT 19123-xxxx
230V 54 A 59 A 18 kW 420 W 75 A 100 A 178 A
TA-U1 19101-xxxx
400V 2,1 A 2,4 A 1,1 kW 80 W 3,0 A 4,5 A 8,0 A
TA-U2 19102-xxxx
400V 4,3 A 5,1 A 2,2 kW 100 W 6 A 9 A 16 A
TA-U4 19104-xxxx
400V 7,0 A 7,8 A 3,7 kW 160 W 9,5 A 14,3 A 25 A
TA-U6 19106-xxxx
400V 10,5 A 12 A 5,5 kW 230 W 13 A 15,2 A 27 A
TA-U6 HT 19107-xxxx
400V 11,5 A 13 A 6,0 kW 250 W 15 A 22,5 A 40 A
TA-U8 19108-xxxx
400V 13,2 A 14,5 A 7,5 kW 280 W 18 A 27 A 47 A
TA-U8 HT 19109-xxxx
400V 13,2 A 14,5 A 7,5 kW 360 W 21 A 30 A 53 A
TA-U10 19110-xxxx
400V 19,1 A 21,0 A 11 kW 390 W 24 A 30 A 53 A
TA-U15 19115-xxxx
400V 26,0 A 29,0 A 15 kW 540 W 34 A 42,5 A 75 A
TA-U22 19122-xxxx
400V 37,0 A 40,3 A 22 kW 640 W 50 A 60 A 107 A
TA-U22 HT 19123-xxxx
400V 38,0 A 41,8 A 22 kW 660 W 50 A 87 A 154 A
TA-U30 19130-xxxx
400V 51,0 A 56,2 A 30 kW 850 W 65 A 98 A 174 A
TA-U30 HT 19131-xxxx
400V 52,0 A 57,2 A 30 kW 850 W 65 A 117 A 208 A
TA-U37 19137-xxxx
400V 64,0 A 70,4 A 37 kW 1080 W 80 A 120 A 213 A
TA-U37 HT 19138-xxxx
400V 64,0 A 70,4 A 37 kW 1100 W 80 A 144 A 255 A
TA-U45 19145-xxxx
400V 77,0 A 84,7 A 45 kW 1300 W 93 A 144 A 255 A
TA-U45 HT 19146-xxxx
400V 77,0 A 84,7 A 45 kW 1300 W 93 A 168 A 298 A
TA-U55 19155-xxxx
400V 94,0 A 103,4 A 55 kW 1600 W 115 A 168 A 298 A
TA-U55 HT 19156-xxxx
400V 94,0 A 103,4 A 55 kW 1650 W 115 A 207 A 366 A
TA-U65 19165-xxxx
400V 110,0 A 121,0 A 65 kW 1900 W 130 A 170 A 300 A
TA-U65 HT 19166-xxxx
400V 110,0 A 121,0 A 65 kW 1950 W 130 A 234 A 412 A
TA-U75 19175-xxxx
400V 127,0 A 139,7 A 75 kW 2200 W 150 A 195 A 345 A
TA-U75 HT 19176-xxxx
400V 127,0 A 139,7 A 75 kW 2250 W 150 A 270 A 478 A
TA-U90 19190-xxxx
400V 150,0 A 165,0 A 90 kW 2700 W 190 A 270 A 478 A
TA-U90 HT 19191-xxxx
400V 160,0 A 165,0 A 95 kW 2800 W 200 A 330 A 585 A
TA-U110 19211-xxxx
400V 180,0 A 192,0 A 110 kW 3320 W 225 A 270 A 478 A
TA-U110 HT 19212-xxxx
400V 180,0 A 192,0 A 110 kW 3450 W 225 A 390 A 690 A
TA-U150 19215-xxxx
400V 250,0 A 270,0 A 150 kW 4300 W 300 A 390 A 690 A
TA-U150 HT 19216-xxxx
400V 250,0 A 270,0 A 150 kW 4400 W 300 A 520 A 919 A
TA-U170 19217-xxxx
400V 280,0 A 280,0 A 170 kW 4900 W 350 A 390 A 690 A
TA-U170 HT 19218-xxxx
400V 280,0 A 280,0 A 170 kW 4900 W 350 A 540 A 956 A
TA-U200 19220-xxxx
400V 330,0 A 352,0 A 200 kW 5800 W 450 A 580 A 1026 A
TA-U250 19225-xxxx
400V 410,0 A 440,0 A 250 kW 7500 W 550 A 820 A 1450 A
TA-U280 19228-xxxx
400V 450,0 A 450,0 A 280 kW 8400 W 630 A 945 A 1665 A
