tae TA-U110 HT User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 1
Appendix 1 list of Parameters
Access explanation
R and RC = Read
RW = Read / Write
RW (0) = Read, Write while staionary
01: EEPROM, SMC and EZU
ID
Name
Value-Range
Default-Value
Unit
Access
1
Memory CMD
0000h ... 333Fh
2000h
[bits]
RW
Bit
Name
Notes
0
Store Parameters
Save parameters on the U-Drive-EEPROM
1
Load Parameters
Load parameters from the U-Drive-EEPROM
2
Store Default Parameters
Save current parameters as "standardparameter" on EEPROM
3
Load Default Parameters
Load standard parameters from EEPROM
4
Store Factory Defaults
Save current parameters as "factory setting” on EEPROM
5
Load Factory Defaults
Load parameters "factory setting” from EEPROM
6
7
8
Store Parameters
Save current parameters onto Smart-Card
9
Load Parameters
Load parameters from Smart-Card
10
11
12
Set Clock
Transfer set time to real-time clock
13
Get Clock
Read real-time clock in cycles
14
15
01: EEPROM, SMC and EZU
ID
Name
Value-Range
Default-Value
Unit
Access
2
Memory STAT
0000h ... 038Fh
---h
[bits]
R
All data bits in parameter 2 are actual values and only 20-40ms is visible
Bit
Name
Notes
0
Store Ok
Parameters saved on U-Drive EEPROM
1
Load Ok
Parameters loaded from U-Drive EEPROM
2
Store Error
Error message while saving the parameters on the U-Drive EEPROM
3
Load Error
Error message while loading the parameters from the U-Drive EEPROM
4
5
6
7
Set Clock Ok
Confirmation: Set time adopted
8
Get Clock Ok
Confirmation: Time read
9
10
11
12
13
14
15
01: EEPROM, SMC and EZU
ID
Name
Value-Range
Default-Value
Unit
Access
4
RTC Second
0 ... 59
---
s
R
5
RTC Minute
0 ... 59
---
min
R
6
RTC Hour
0 ... 23
---
h
R
