June 2003 IPN: M5000-00-105 Servicing Intrinsically Safe radios A - 11
Servicing Intrinsically Safe radios
Intrinsically Safe radios
Intrinsically Safe (IS) radios are certified by a
third party to be safe to use in particular
hazardous locations.
Tait Orca 5000 IS portable radios can be
identified by one or more of the following:
■ Yellow labels
■ IS circle logo
■ FM diamond logo
A radio with any of these features must only be
serviced by an agency certified by both the
approval authority and Tait Electronics Ltd.
Any unauthorised repair or substitution of
parts invalidates the intrinsic safety rating and
the third party IS approval.
IS PCB servicing requirements
Tait Orca 5000 IS portable radios must be
returned to an authorised Tait branch or
subsidiary for servicing. Any unauthorised
repair or substitution of parts invalidates the
intrinsic safety rating.
FM approval
Tait Orca 5000 IS portable radios and accesso-
ries are approved by Factory Mutual Corpora-
tion (FM) to the following ratings:
■ IS/I/1/CD/T3C Ta=40°C
■ NI/I/2/ABCD/T3C Ta=40°C
See Table A-3 on page A-12 for more detail on
these ratings.
FM approved products
Radios with the following product code have
FM IS approval:
■ TOP-x24x0-B2
■ TOP-x24x0-T2
■ TOP-x25x0-B2
■ TOP-x25x0-T2
■ TOP-x26x0-B2
■ TOP-x26x0-T2
For more information about the Tait Orca
product code, refer to page page A-5.
FM approved accessories
The following accessories are approved for use
with the Tait Orca 5000 IS portable radios.
■ TOPB200-IF NiCd IS battery pack
■ TOPA-AA-003G rugged speaker-micro-
phone
■ TOPA-AA-004G RF speaker-microphone
■ TOPA-AA-005 adapter (required for use
with TOPA-AA-012/013)
■ TOPA-AA-012 heavy duty headset with
noise cancelling microphone (over the
head)
■ TOPA-AA-013 heavy duty headset with
noise cancelling microphone (behind
neck)
■ T952-051 rugged earphone kit (optional
for use with TOPA-AA-003/004)
TOPB200-IF IS battery pack
The shift life of the TOPB200-IF IS battery
pack may be reduced by up to 10 percent when
compared to its non-IS equivalent.
The battery pack should not be charged in a
hazardous location.
