June 2003 IPN: M5000-00-105 Servicing the radio D - 3
Servicing the radio
Servicing of Tait Orca 5000 portable radios is
limited to key mechanical and ancillary devic-
es. These include:
■ the front panel assembly;
■ the lens (Orca 5015/2x/35/40);
■ the PTT keypad;
■ the speaker;
■ the keypad (Orca 5015/2x/35/40);
■ the LCD display (Orca 5015/2x/35/40);
■ the shield, complete with user interface
PCB assembly and polyester dome (Orca
5015/2x/35/40);
■ the main PCB assembly;
■ the antenna connector;
■ the channel selector switch;
■ the volume control switch;
■ the microphone;
■ the speaker contacts;
■ the battery contacts;
■ the PTT tact switch;
■ the RF out assembly
■ the auxiliary flexible PCB
■ the rear panel; and
■ the chassis.
A list of spares kits available for servicing Tait
Orca 5000 portable radios is shown in Table
D-1 on page D-17. These spares can be ordered
from your local Tait dealer.
Screw head types
Most of the screws in Tait Orca 5000 portable
radios are Torx head screws, and so a Torx T6
driver bit is supplied as part of the service kit.
When removing screws be sure to use the
correct driver.
Torx head 1.8x5 mm screws should be
removed using the supplied Torx T6 driver.
When replacing these screws, set the driver to
2in.lb (0.23Nm).
