C - 14 Fault finding charts June 2003 IPN: M5000-00-105
Figure C-6: No transmit audio
NO
Is the flexible loom
inserted correctly?
YES
YES
Is the flexible loom damaged?
When an external accessory is
plugged in, is there microphone
audio for the accessory?
YES
Return to nearest
Tait dealer
No transmit audio
YES
Is the internal
microphone working?
Ensure loom is properly fitted
into the socket on the PCB.
Replace internal microphone.
NO
NO
Replace flexible loom.
NO
To Next Page
