June 2003 IPN: M5000-00-105 Spares kits D - 17
Spares kits
The following table shows a list of spares kits
which are currently available for servicing Tait
Orca 5000 portable radios. Spares kits are
designed to service 100 radios, and can be
ordered from your local Tait dealer.
Table D-1: Spares kits
The contents of the Orca 5000 low, mid and
high tier spares kits (TOPA-SP-401G,
TOPA-SP-402G and TOPA-SP-403G) are
shown in Tables D-2, D-3 and D-4. The
contents of the Orca 5000 portable radio re-
skinning kits are shown in Tables D-5, D-6 and
D-7.
Information contained in the tables
Note that the ‘IPN’ column is the ten digit
‘internal part number’ which uniquely identi-
fies any component used in a Tait product.
The numbers in the ‘Reference’ column are
Figure numbers in which the spares item is
shown, and the number in brackets refers to
the numbered legend within each figure.
PCB Product Codes
Tait Orca 5000 main PCBs are available on an
exchange basis from Technical Support at Tait
Electronics Ltd. When ordering, use the
following naming convention
TOP-XXXXX-KS.
For example, a replacement main PCB for a
TOP-B2620-T0 is a TOP-B2620-KS.
The Tait Orca product code can be found on
the chassis type approval label, which is visible
when the battery is removed.
Product code Description
TOPA-SP-401G Orca 5010/11/30 spares kit
TOPA-SP-402G Orca 5035 spares kit
TOPA-SP-403G Orca 5015/2x/40 spares kit
TOPA-SP-404 Orca 5010/11/30 re-skinning kit
TOPA-SP-405 Orca 5035 re-skinning kit
TOPA-SP-406 Orca 5020/40 re-skinning kit
TOPA-SP-407 Orca 5015/2x/35/40 U/I PCB +
shield
TOPA-SP-408 Orca 5015/21 re-skinning kit
TOPA-SP-504 Battery catch x 10
TOPA-SP-506 Orca 5000 series volume knobs x 10
TOPA-SP-507 Orca 5000 series channel knobs x 10
