TM8100/TM8200 Service Manual General Information 131
© Tait Electronics Limited November 2007
4.9 Defining Frequency Bands
Where test procedures or figures differ according to the frequency band of
the radio, the frequency band is given in brackets. The frequency band may
be referred to as either ‘VHF’ (very high frequency) or ‘UHF’ (ultra-high
frequency) or identified by the frequency sub-band, such as ‘B1’ or ‘H7’.
For example:
In some cases, differences in performance over the frequency band mean
that the K5 frequency band may be further divided, into “700MHz” and
“800MHz”.
The frequency bands for TM8100/TM8200 radios are listed in Table 4.10.
The relevant frequencies for the different bands are listed in this table.
RF output power: > 60W (VHF), > 52W (UHF)
current: < 15A (VHF), < 12A (UHF)
Table 4.10 Defining frequency bands
Frequency identification Frequency sub-band
VHF A band
B band
C band
D band
A4 = 66MHz to 88MHz
B1 = 136MHz to 174MHz
C0 = 174MHz to 225MHz
D1 = 216MHz to 266MHz
UHF G band
H band
G2 = 350MHz to 400MHz
H5 = 400MHz to 470MHz
H6 = 450MHz to 530MHz
H7 = 450MHz to 520MHz
700/
800
MHz
K band K5 = 762 to 870MHz (Tx)
762 to 776MHz and
850 to 870MHz (Rx)
