238 Frequency Synthesizer Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited November 2007
Figure 9.18 FCL circuitry under and adjacent the FCL TOP can
Via for
measuring
VCXO output
Position R527
for Tasks 38
and 39
F
C
L
_
TO
P
IC506
L501
Q504
IC509
R520
R510
R527
R5044
A4 band
Via for
measuring
VCXO output
Position R527
here for Tasks 38
and 39
