TM8100/TM8200 Service Manual Description 35
© Tait Electronics Limited November 2007
Figure 2.7 Components of the RJ45 control head
B
control-head board
E
PCB bracket
C
control-head loom with female-female adapter
F
front panel
D
3 x 8 PT screw (x4)
G
RJ45 bung (x2)
B
D
E
F
G
x4
C
x2
