30 CCDI TM8100/TM8200 Computer-Controlled Data Interface (CCDI) Protocol Manual
© Tait Electronics Limited April 2007
1.9.5 QUERY
The QUERY command requests information from the radio.
Format q [SIZE] [QUERY_TYPE] [DATA] [CHECKSUM]
‘q’ is sent as a single ASCII character and represents the QUERY
command.
[QUERY_TYPE] is a single ASCII character representing the query
type required.
[DATA] is a number with up to three-digits which identifies the CCTM
command which is sent.
Note If no [QUERY_TYPE] is sent, then the QUERY command will
default to [QUERY_TYPE] = 0.
[QUERY_TYPE] [DATA] Function Support
0
(model and CCDI
version)
none Query the radio model and CCDI version. Data is returned
as a MODEL message.
Yes
1
(query SDM)
none The buffered SDM data is returned to the PC as a
GET_SDM message. The SDM buffer is then cleared.
Available in conventional mode only.
Yes
3
(version)
none Query the radio version information. The data is returned
to the PC as a RADIO_VERSION message. Refer to
“RADIO_VERSIONS”.
Yes
4
(serial number)
none Query the serial number. Refer to “RADIO_SERIAL”.Yes
5
(CCTM)
047 PA temperature. Returned to the PC as a
CCTM_QUERY_RESULT message. Refer to
“CCTM_QUERY_RESULTS”.
TM8100: from v2.10
TM8200: No
063 Averaged RSSI level. Returned to the PC as a
CCTM_QUERY_RESULT message.
TM8100: from v2.09
TM8200: No
064 Raw RSSI level. Returned to the PC as a
CCTM_QUERY_RESULT message.
318 Forward power. Returned to the PC as a
CCTM_QUERY_RESULT message.
319 Reverse power. Returned to the PC as a
CCTM_QUERY_RESULT message.
6
(GPS)
none Query GPS. GPS data is returned packetised as though the
TM8100/TM8200 is a polling radio.
TM8100: from v2.10
TM8200: No
7
(display)
0 Returns the text of the entire display. Non-ASCII text is
ignored.
TM8100: No
TM8200: from v3.03
